17/08/2020

Efficient bijective parameterizations

Jian-Ping Su, Chunyang Ye, Ligang Liu, Xiao-Ming Fu

Keywords: coarse shell meshes, triangle inequality-based barriers, bijective parameterizations

Abstract Paper Similar Papers

Abstract: We propose a novel method to efficiently compute bijective parameterizations with low distortion on disk topology meshes. Our method relies on a second-order solver. To design an efficient solver, we develop two key techniques. First, we propose a coarse shell to substantially reduce the number of collision constraints that are used to guarantee overlap-free boundaries. During the optimization process, the shell ensures the Hessian matrix with a fixed nonzero structure and a low density, thereby significantly accelerating the optimization. The second is a triangle inequality-based barrier function that effectively ensures non-intersecting boundaries. Our barrier function is C∞ inside the locally supported region and its convex second-order approximation is able to be analytically obtained. Compared to state-of-the-art methods for optimizing bijective parameterizations, our method exhibits better scalability and is about six times faster. The performance of our bijective parameterization algorithm is comparable to state-of-the-art methods of locally flip-free parameterizations. A large number of experimental results have shown the capability and feasibility of our method.

The video of this talk cannot be embedded. You can watch it here:
https://dl.acm.org/doi/10.1145/3386569.3392435#sec-supp
(Link will open in new window)
 0
 0
 0
 0
  Share
This is an embedded video. Talk and the respective paper are published at SIGGRAPH 2020 virtual conference. If you are one of the authors of the paper and want to manage your upload, see the question "My papertalk has been externally embedded..." in the FAQ section.
